Model type ETL DLC 130LM/W led shoe box light 100w led parking lot pole light

FOB Reference Price:Get Latest Price
US $30-90 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
Item Type:
Street Lights
Input Voltage(V):
AC85-277
Lamp Luminous Flux(lm):
19500
CRI (Ra>):
85
Working Temperature(℃):
-45 - +50
Working Lifetime(Hour):
50000
IP Rating:
IP65
Certification:
BV, C-tick, CCC, CE, CQC, EMC, Energy Star, ETL, FCC, FDA, GOST, GS, LVD, PSE, REACH, RoHS, SAA, SASO, UL, VDE
Warranty(Year):
5
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LUX
Model Number:
LX-SL77D
Name:
ETL DLC 130LM/W led shoe box light 100w led parking lot pole light
Lamp Power(W):
150
Lamp Body Material:
Aluminum
LED Light Source:
3030
Lamp Luminous Efficiency(lm/w):
130
Color Temperature(CCT):
WW/PW/CW
Supply Ability
Supply Ability:
500 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton and inner box
Port
shenzhen
Lead Time :
7-10days

Model type ETL DLC 130LM/W led shoe box light 100w led parking lot pole light



Main parameters  of Model type ETL DLC 130LM/W led shoe box light 100w led parking lot pole light



Model No.

LX-PL

Equivalent

300W High Pressure Sodium Lamp

LED Light Source48

 3030 Brand chip

LED Luminous Efficiency

>120-130 lm/w

Lamp Total Power

100-300W

Power Efficiency

>95%

LED Luminous Efficacy

>170 lm/w

Lamp Rated Luminous Flux

>19500 lm

Lamp Rated Luminous Efficiency

>130 lm/W

Color Rendering Index(CRI)

Ra>85

Color Temperature

Cool white: 5700-8000K

Pure white: 4500-5500K

Warm white: 2700-3500K

Beam Angle

150x70°

Input Voltage

 AC85-305/DC12/24V

Frequency Range

47-63Hz

Power Factor(PF)

>0.95

Total Harmonic Distortion(THD)

< 15%

Storage Temperature

-40--+80

Working Environment

-40--+50 ; 10%-95%RH

Junction Temperature(Tj)

60 ± 10%(ta=25)

Light Body and Lampshade Material

Aluminum Alloy

Working Lifetime

> 50,000hrs

IP Rating

IP65



Note: For Modern design ETL DLC 130LM/W led shoe box light 100w led parking lot pole light, the wattage from 30-150w are available,



The comparation of ETL DLC 130LM/W led shoe box light 100w led parking lot pole light





Detail of Modern design ETL DLC 130LM/W led shoe box light 100w led parking lot pole light

1. High grade components, such as LED ;
2. LED Chip: High brightness  osram 3030
3. LED Driver: External Meanwell driver
4. Warm and cold color temperature are available
5. Quick and easy installation to minimize retrofit costs.
6. Patented heat dissipation technology for radiator;
7. Aluminum 6063 for resistance to corrosion, seawater, oil and lubricant etc;
8. Acrylic sealing reflector around LED; anodized oxide treated aluminum reflector & acrylic reflector available;
9.Closed corrosion-proof silicone ring for dustproof and waterproof
10.Beam angle: 150x70 degree. Dustproof cover, or Crystal PC reflector available
11.Lamp surface treated with anodization, corrosion-resistant, shake-resistant and artistic appearance
12.Terrific heat dissipation technology: LED temperature will be rapid transfered to fin-style heatsink through heatpipe
13.Energy saving: Replace 160-200w traditional lamps, saving more than 80%
14.Eco-friendly:  No lead, mercury, UV interference
15.Long lifespan: more than 50000 hours, If LED works 11-12 hours per day, it can work over 10 years.
16.Certificate: CE,RoHS,SAA,PSE,IP65
17.Warranty: 5 years

 Notes of ETL DLC 130LM/W led shoe box light 100w led parking lot pole light

1. When open the package, please check whether the inside is including product, accessory, label, certificate quality. And please assure that the light is perfect without any damage.

2. The wires of LED Street Light is three-core, the standard size of the wire is 3*1mm²or3*1.5mm² and the outer diameter isΦ7~12mm, brown wire is live line, blue wire is null line, yellow& green is ground line.

3. LED Street Light will work when the voltage up to rated voltage, so please be sure the voltage within the requested range, or it will damage the light which can’t be repaired.

4. when the electrical continuity is connected, the lead wire should be in electric insulating



Application of ETL DLC 130LM/W led shoe box light 100w led parking lot pole light

Road lighting, community lighting, park lot lighting, dock lighting

Main Road, Sidewalk, Square, School, Park, Garden, Factory, Residential Places, Villa and so on.

Packing size

Net Weight7.3kgs
Gross Weight8.8kgs
Package Size(cm)84x39*19cm  /1 pcs
