Quick Details

  • Light Source: LED
  • Item Type: Street Lights
  • LED Light Source: CREE XTE
  • Input Voltage(V): 100-277
  • Lamp Power(W): 80
  • Lamp Luminous Flux(lm): 8000
  • Lamp Luminous Efficiency(lm/w): 100
  • CRI (Ra>): 75
  • Color Temperature(CCT): WW/NW/CW
  • Working Temperature(℃): -40 - +50
  • Working Lifetime(Hour): 50000
  • Lamp Body Material: Aluminum
  • IP Rating: IP65
  • Certification: BV, C-tick, CCC, CE, CQC, EMC, Energy Star, ETL, FCC, FDA, GOST, GS, LVD, PSE, REACH, RoHS, SAA, SASO, UL, VDE
  • Warranty(Year): 3
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: LUX
  • Model Number: LX-SL72C-80W
  • Item: meanwell 5 year warranty competitive price led street lights 80 watt
  • Led chip: CREE/PHILIPS/BRIDGELUX
  • Led QTY: 72pcs
  • Lamp watts: 80w/90W/120W/150W
  • Input voltage: AC100-277V/DC10-30V
  • Lamp size: 476.2*304*128mm
  • NW/GW: 5.2/6.5KG
  • Pole diameter: 60-61mm
  • Driver: Meanwell/Normal
  • Warranty: 5 years

Packaging & Delivery

Packaging Details: neutral packing,carton with protective casing
Delivery Detail: 5-7 workdays after payment

meanwell 5 year warranty competitive price  led street lights 80 watt



Specifications:

1. Product Name:80w led street light

2. LED: CREE-XTE

3. Lifespan for LED lighting source:> 50,000 hours

4. Uniformity of illuminance : 0.7

5. The curve of light distribution:Asymmetric (Bat Wing) / Rectangular Beam

6.  Case Color Available::gray ,blue,red,white available

7. Size for pole diameter:50 or 60mm

8. Distribution of the light:LED+ Optical glass lens

9. IP Rating: IP65

10. Working Temperature:-40 ºC ~ 50 ºC

11. Working Humidity:-10 ~ 90%RH

12. Storage Temperature:-25 ºC ~65 ºC

13. Certification: CE, ROHS



Tech data:

Power80W
ModelLX-SL72C-80W
CCT2800-7000K
CRIRA>85
VoltageDC10-28V/AC85-265V
IPgradeIP65
CCT6000-6500K
CertificationCE/ROHS
N.W/G.W5.2/6.5KG
Warranty5 years





Model ranges:

LX-SL-30WD, 60WD, 90WD, 120WD, 150WD, 180WD, 210WD



Input Voltage:

1. AC 110V & AC 220V

2. DC24V



Features:

1. CE, RoHS & IP65 approved, UL Meanwell LED Driver available.

2. Input Voltage Option: AC 85-265V or DC24V

3. LED Brand: USD Bridgelux LED Chip/CREE XTE chip

4. Corrosivity Resistance

5. Good heat disperation with 3-D heat dispersion

6. 5 years warranty



Product Description

Model D-B

30W

60W

90W

120W

150W

180W

210W

LED Model

Bridgelux LED

LED Qty

24

48

72

96

120

144

168

IP Rate

IP65

Input Voltage

AC86-265V/DC12V/DC24V

Installation

Adjustable

Vertical 0-180°

LED Driver

Meanwell

Warranty

5 Years Warranty



Model D-C

60W

100W

150W

180W

240W

280W

320W

LED Model

CREE LED

LED Qty

24

48

72

96

120

144

168

IP Rate

IP65

Input Voltage

AC86-265V/DC12V/DC24V

Installation

Adjustable

Vertical 0-180°

LED Driver

Meanwell

Warranty

5 Years Warranty



Application:

1. Tunnel

2. Gas Station

3. Factory

4. Warehouse

5. Hall

6. Square

7. Parking Lot

8. Supermarket

9. Stadium

10. Football Field, etc.





Installation Notes:



Step 1: Power must be cut off before installation, it's not allowed to do all this with power on.



Step 2: Put two screws on where required the same size as position, what it's indicated in the diagram.



Step 3: Turn up to any beam angle needed by rotating the lamp body.



Step 4: Make connection of Blue with L line, Brown with N line and Yellow Green with Earth Line, turn it on when it's connected properly.



Step 5: Pictures will be offer to help installation.







Trade Terms:



1. Supply ability:10000-15000 units/month



2. MOQ:1 unit 90 watt led street light.



3. OEM/ODM:Supply.



4. Available trade terms:TT, LC AT SIGHT,



5. Delivery time:5-25 days after receiving you deposit.



6. Payment:T/T By 30% in advance, 70% before loading the container.



7. Guarantee:five years







OEM Service:



The most outstanding ability of our factory is to do special required LED Light for our customers .We have done a lot of led lights that other factories can not do or don't do. We also can provide the whole solution for your lighting system.
